Power Pack, 120-277V, 50/60Hz, 24VDC, 225mA,

The BZ-200 power pack switches connected loads On and Off in response to Wattstopper low voltage occupancy sensors. It also provides up to 225mA at 24VDC to power the sensors. This device is constructed with environmentally friendly materials and is RoHS-compliant.

Send
Save as PDF
Added to Favorites Go to favorites

Remove from favorites?

Something went wrong. Please try again later.

Features

Efficient switching power supply provides optimized current output based on number of sensors
Includes short circuit and thermal protection
LED indicates status of relay or presence of low-voltage overcurrent
UL 2043 plenum rated for cost-effective installation
UL listed for control of lighting and plug loads
Tested to NEMA 410 criteria for electronic ballast and driver inrush current
1/2”” threaded nipple attaches to standard electrical enclosures through 1/2”” knockouts

Specifications

General Info

Color	White
Product Series	BZ
Type	Power Pack
Material	Plastic
Application Sector	Commercial
Product Line	Wattstopper
Country Of Origin	China
Installation Location	Ceiling
Warranty Type	5-Year
UPC Number	754182938032

Dimensions

Product Depth US	1.4 in
Product Height US	3.0 in
Product Volume US	42.0 cu in
Product Width US	3.0 in
Product Weight US	0.4 lb

Additional Information

RoHS Compliant

Yes

This product meets the material restrictions of Article 4 of the RoHS Directive (2011/65/EU), including Commission Delegated Directive 2015/863.

Technical Information

Wire Connection Type	Wire Leads
Connection Type	Wired
Indoor/Outdoor	Indoor
Input Voltage	120 to 277 VAC
Line Frequency	50 Hz, 60 Hz
Mounting Type	1/2 in Knockout
Operating Temperature	-4°-131°F
Operating Temperature Max	131 °F
Operating Temperature Min	-4 °F
Operating Humidity	5-95% RH (Non-Condensing)
Output Voltage	24 VDC
Storage Temperature	-40° - 176° F
Wire Gauge	18-22 AWG
